The TDJ04-1105 is an economical 1000 lbs hydraulic engine crane for automotive workshops, repair garages and maintenance operations. It combines a compact frame, 2-position boom adjustment and a 3 ton hydraulic long ram jack for controlled engine lifting and positioning tasks.
[Main product image]
1000 lbs Rated Capacity and 1290mm Working Range
The crane has a rated capacity of 1000 lbs / 454 kg. The supplied factory notes separately list a 1100 lbs / 499 kg maximum technical value; use 1000 lbs as the normal operating capacity unless formal documentation states otherwise.
Rated capacity: 1000 lbs / 454 kg
Factory-stated maximum technical value: 1100 lbs / 499 kg
Working range: 870-1290 mm / 34.3-50.8 in
Suitable for controlled engine lifting and positioning work
2-Position Adjustable Boom
The boom can be set in two positions to help operators select the appropriate reach for the work area. Capacity may vary with the selected boom position; always follow the capacity label and operating instructions.
Adjustable boom positions: 1-2
Flexible reach adjustment for workshop tasks
Do not assume the same capacity applies at both boom positions
[Boom adjustment detail]
3 Ton Hydraulic Long Ram Jack
This crane uses a 3 ton hydraulic long ram jack for lifting action. The hydraulic piston rod has a 28 mm / 1.10 in diameter and is hard chrome plated.
Important: The 3 ton specification applies to the hydraulic long ram jack. The complete crane must be operated only within its 1000 lbs / 454 kg rated capacity.
Hydraulic long ram jack: 3 ton
Piston rod diameter: 28 mm / 1.10 in
Piston rod finish: hard chrome plated
Hydraulic system designed for controlled lifting and lowering
[Hydraulic ram detail]
Q235 Steel Frame
The main structure uses Q235 steel square tubing with a 2.0 mm / 0.08 in wall thickness. The economical design provides a practical lifting solution for suitable workshop engine-handling requirements.
Carton 1: 1180 x 280 x 180 mm / 46.5 x 11.0 x 7.1 in
Carton 2: 340 x 330 x 320 mm / 13.4 x 13.0 x 12.6 in
Reference loading quantity: 280 sets per 20 ft container
Confirm loading quantity, carton marks, lead time and export-packing requirements before order confirmation
Why Choose This 1000 lbs Engine Crane?
Clear rated capacity: 1000 lbs / 454 kg for defined engine-handling tasks.
Compact working range: 870-1290 mm / 34.3-50.8 in for workshop use.
Adjustable boom: Two positions help match reach to the lifting task.
Hydraulic lifting system: Uses a 3 ton hydraulic long ram jack.
Q235 steel structure: Square-tube frame with 2.0 mm wall thickness.
Practical packing: One set in two cartons for shipment and storage.
Safety and Compliance Notes
Do not exceed the 1000 lbs / 454 kg rated capacity.
The 1100 lbs figure is a factory-stated technical maximum, not the normal operating capacity.
The 3 ton hydraulic long ram jack does not change the crane's 1000 lbs rated capacity.
Capacity may vary by boom position; follow the capacity label and operating instructions.
Use only on a firm, level surface.
Inspect the hook, chain, hydraulic ram, pins, frame and fasteners before use.
Never work beneath a suspended engine or component.
No CE/GS declaration is supplied for this model. Confirm destination-market compliance requirements before ordering.
FAQ
What is the rated capacity?
The crane is rated for 1000 lbs / 454 kg.
Why is 1100 lbs also listed?
The supplied factory notes list 1100 lbs / 499 kg as a maximum technical value. Use the 1000 lbs rated capacity for normal operation unless the manufacturer provides formal documentation stating otherwise.
What is the working range?
The specified working range is 870-1290 mm / 34.3-50.8 in.
Can the boom be adjusted?
Yes. The boom has two adjustment positions. Follow the relevant capacity label and operating instructions for the selected position.
Does the 3 ton hydraulic jack mean the crane can lift 3 tons?
No. The 3 ton figure describes the hydraulic long ram jack. The complete crane is rated at 1000 lbs / 454 kg.
Is CE or GS certification included?
No CE/GS declaration is supplied for this model. Confirm required certification and compliance documents before ordering.
Request a Quote
Need a 1000 lbs hydraulic engine crane for workshop, wholesale or distribution requirements? Send your destination, quantity and delivery requirements to receive a current quotation and packing confirmation.
OEM are welcome for us. Customers’ brand, logo, label can be customized for the products and carton package, but based on a certain quantity.
Are you a factory or trading company?
We are an integrated industry and trade company, a production source factory
Can I get a sample?
Yes. Samples are welcome for us. But products cost and few extra cost will be charged from customer, the sample cost will be returned to customer once the order confirmed.
