What core lifting performance does this air hydraulic trolley jack deliver?
‑ Dual‑rating lifting capacity: 60‑ton low‑profile mode and 30‑ton high‑stroke mode, designed for heavy‑duty commercial vehicles including trucks, buses and large engineering vehicles.
‑ Working air pressure ranges from 0.8‑1.2Mpa, matches standard workshop air compressor systems widely used in heavy‑duty repair workshops.
‑ Minimum lifting height is 195mm, easy to slide under heavy‑duty vehicles with compact under‑chassis space. Maximum lifting height reaches 400mm to create adequate working clearance for axle, tire and suspension maintenance.
‑ Comes with three removable shim blocks: 20mm,40mm,60mm. You can stack these shims flexibly to raise effective lifting height according to different vehicle chassis conditions.
‑ Combined air‑hydraulic power structure: compressed air drives hydraulic system, greatly reduces manual pumping workload for frequent heavy‑load lifting jobs.
What is the actual day‑to‑day operating experience?
‑ Heavy‑duty large rubber trolley wheels, roll smoothly across rough concrete workshop floors. You can push and position this heavy jack under vehicle axles without extra lifting labor.
‑ Integrated air‑hydraulic control unit, one‑handle operation for lifting and lowering. Operators can adjust lifting speed steadily, avoid sudden impact to vehicle chassis.
‑ Robust thick‑welded steel main body structure, anti‑deformation under long‑term heavy load, suitable for high‑intensity daily commercial repair work.
‑ Interchangeable height‑increase shims are easy to attach and detach. You can quickly combine different shim heights without extra tools to fit multiple heavy‑duty vehicle models.
‑ Compact trolley‑style whole‑machine layout. Even for crowded heavy‑repair workshops, this jack does not occupy excessive storage space when idle.
How about packaging & wholesale shipping conditions?
‑ Packing: 1 piece per export carton; carton dimension:67×30×37 cm.
‑ Reinforced export‑grade carton shell protects the air hydraulic trolley jack against collision and impact damage during ocean freight and land transit.
‑ Compact outer‑package dimension optimizes container loading efficiency, helps B2B buyers calculate unit freight cost for bulk orders.
‑ Finished export packaging is ready‑for‑sale. Distributors and resellers do not need secondary repacking, saving warehouse labor and processing time.
What safety rules should you follow before using it?
‑ Only operate on flat, solid and firm ground. Never deploy the jack on soft soil, sand, mud or sloped surfaces to prevent tipping risk under heavy load.
‑ Strictly follow dual‑capacity rating: do not exceed 60‑ton load for low‑stroke work; never go beyond 30‑ton limit for full‑height lifting. Overloading will bring permanent structural damage and safety hazards.
‑ After lifting the heavy vehicle to target height, you must place heavy‑duty safety axle stands for secondary support. Never work underneath vehicles supported only by this trolley jack.
‑ Keep working air pressure strictly within 0.8‑1.2Mpa range. Do not apply over‑pressure air supply, which will damage internal hydraulic‑air components.
‑ Before each use, inspect air pipes, hydraulic seals, welding joints and shim blocks for cracks, oil leakage or wear. Replace damaged spare parts before operation.
Why choose TQFLL‑2360 60/30 ton air hydraulic trolley jack for your business?
‑ Dual‑capacity design covers two working scenarios with one single jack, reducing buyers’ tool procurement cost and inventory pressure.
‑ Air‑hydraulic hybrid power eliminates tiring manual pumping, improving work efficiency for high‑volume heavy‑vehicle repair tasks.
‑ Flexible shim height accessories expand adaptability for various heavy‑duty vehicle chassis heights.
‑ Durable welded steel frame and trolley wheel design meet harsh workshop working environment. It is a high‑demand, profitable heavy‑duty garage tool for wholesale and retail.
Can you do OEM for us ?
OEM are welcome for us. Customers’ brand, logo, label can be customized for the products and carton package, but based on a certain quantity.
Are you a factory or trading company?
We are an integrated industry and trade company, a production source factory
Can I get a sample?
Yes. Samples are welcome for us. But products cost and few extra cost will be charged from customer, the sample cost will be returned to customer once the order confirmed.
